iMERLYN Pure Sinewave UPS Model 1850 (24V) SW
- Weight16.4kg
- Output Voltage230 Voltage
- Dimensions (L*W*H)43.3x46.3x23.2
SALIENT FEATURES:
iMerlyn Is the Intelligent premium UPS Series that Has Heavy Load Handling Capacity and adds to the Beauty of your home with its inspiring Looks. its 5 Stage Battery Charging Mechanism Keeps the Battery Healthy & also Provided Longer Battery Life.
- Micro controlled based Intelligent Control Design.
- Display Indications (Status & Fault).
- High Peak Current Handling Capability.
MICROTEK iMERLYN Pure Sinewave UPS Model 1850 (24V) SW Micro Controller design based, LARGEST SELLING PREMIUM SERIES of Extended Backup External Battery UPS Systems. It comes with many user friendly features. It has Voltage Range Selection Switch and can be operated in Inverter Range from 100V~300V and UPS Range from 180V~260V.
|
Rated Capacity |
1600 VA |
|
Output Power |
1275 Watts |
|
Battery |
2 Battery System (24V) |
|
Wave form |
Pure Sinewave |
|
Warranty |
2 Years |
MICROTEK iMERLYN Pure Sinewave UPS Model 1850 (24V) SW Micro Controller design based, LARGEST SELLING PREMIUM SERIES of Extended Backup External Battery UPS Systems. It comes with many user friendly features. It has Voltage Range Selection Switch and can be operated in Inverter Range from 100V~300V and UPS Range from 180V~260V.
|
Rated Capacity |
1600 VA |
|
Output Power |
1275 Watts |
|
Battery |
2 Battery System (24V) |
|
Wave form |
Pure Sinewave |
|
Warranty |
2 Years |
- Micro controlled based Intelligent Control Design.
- Display Indications (Status & Fault).
- High Peak Current Handling Capability.
- High Voltage Surge Protection.
- Charging Mode, Load Type & Battery Type Selection Switches.
- Re-Settable Circuit Breaker.
- Smart Thermal Management Protection.
DISPLAY
- MAINS ON
- UPS ON
- BATTERY CHARGING
- OVERLOAD
- BATTERY LOW
- CB TRIP
| MODEL | iMERLYN 1850 (24) SW |
|---|---|
| INPUT | |
| INPUT VOLTAGE (Standard range) | 100V ~ 300V |
| INPUT VOLTAGE (Narrow Range) | 180V ~ 260V |
| OUTPUT | |
| OUTPUT VOLTAGE (Main Mode) | Same as INPUT |
| OUTPUT VOLTAGE (UPS Mode) | 210V + 10% |
| OUTPUT FREQUENCY (UPS Mode) | 50 Hz ± 0.1 Hz |
| OUTPUT WAVE FROM (Main Mode) | Same as INPUT |
| OUTPUT WAVE FROM (UPS Mode) | Pure Sinewave |
| CHANGE-OVER | |
| SWITCHOVER (Mains>UPS / UPS>Mains) | AUTOMATIC |
| UPS TRANSFER TIME | <15 msec |
| TECHNOLOGY | |
| DESIGN | Micro Controller Based Design With IPS Technology |
| BATTERY CHARGING CURRENT | Constant Charging Approx. 10% of the Rated Battery Current in AH |
| UPS OVERLOAD / UPS SHORT CIRCUIT | 110% / 300% |
| BROWNS ON MAINS VOLTAGE | 100V + 40V |
| EFFICIENCY (BATTERY MODE) | >80% |
| AUTO RESET FEATURE | YES |
| OPERATING TEMPRATURE | 0°~45° Degree Celsius |
| WEIGHT (KG) | 17.48 KG |
| DIMENTION (LxWxH) in CM | 43.3x46.3x23.2 CM |
