iMERLYN Digital UPS Model 1050 (12V) DG
SKU: 899-981-1050
CATEGORY: INVERTER/HOME UPS
₹4,718
30% OFF
MRP: ₹6,740
Out of stock
- Weight8.2 KG
- Output Voltage900 VA
- Dimensions (L*W*H)L*W*H - 39.2*20.2*34.5
SALIENT FEATURES:
- Inverter Details- Type: Advanced Digital; VA Rating: 900VA/725W; Max. Peak Load: 850 watt, Inverter Compatibility: Designed for all types of power cut situations with high charge acceptance and low maintenance
- Battery Compatibility - Compatible with 1 X (12V) battery of Capacity Between 100 Ah-200 Ah Battery. The Ups Supports wide range of Batteries Like A Flat Plate, Tubular, Smf (To Be Purchased Separately)
- Display: Digital LED display for status of Power back-up/battery charging time in Hours and Minute
- Item Dimensions: 34 x38.2 x 19.8 CM; Item Weight: 8Kg
MICROTEK iMERLYN UPS 1050 (12V) DG is Micro Controller design based, LARGEST SELLING PREMIUM SERIES of Extended Backup External Battery UPS Systems. It comes with many user friendly features. It has Voltage Range Selection Switch and can be operated in Inverter Range from 90V~300V and UPS Range from 180V~260V.
| Rated Capacity | 900 VA |
| Output Power | 725 Watts |
| Battery | 1 Battery System (12V) |
| Wave form | TPZi Wave |
| Warranty | 2 Years |
MICROTEK iMERLYN UPS 1050 (12V) DG is Micro Controller design based, LARGEST SELLING PREMIUM SERIES of Extended Backup External Battery UPS Systems. It comes with many user friendly features. It has Voltage Range Selection Switch and can be operated in Inverter Range from 90V~300V and UPS Range from 180V~260V.
| Rated Capacity | 900 VA |
| Output Power | 725 Watts |
| Battery | 1 Battery System (12V) |
| Wave form | TPZi Wave |
| Warranty | 2 Years |
- Micro controlled based Intelligent Control Design.
- Display Indications (Status & Fault).
- High Peak Current Handling Capability.
- High Voltage Surge Protection.
- Charging Mode, Load Type & Battery Type Selection Switches.
- Re-Settable Circuit Breaker.
- Smart Thermal Management Protection.
DISPLAY
- MAINS ON
- UPS ON
- BATTERY CHARGING
- OVERLOAD
- BATTERY LOW
- CB TRIP
| MODEL | iMERLYN 1050 (12) DG |
|---|---|
| INPUT | |
| INPUT VOLTAGE (Standard range) | 90V ~ 300V |
| INPUT VOLTAGE (Narrow Range) | 180V ~ 260V |
| OUTPUT | |
| OUTPUT VOLTAGE (Main Mode) | Same as INPUT |
| OUTPUT VOLTAGE (UPS Mode) | 200V ~ 230V + 10% |
| OUTPUT FREQUENCY (UPS Mode) | 50 Hz ± 0.1 Hz |
| OUTPUT WAVE FROM (Main Mode) | Same as INPUT |
| OUTPUT WAVE FROM (UPS Mode) | TPZi Wave form (Trape Zoidal waveform) |
| CHANGE-OVER | |
| SWITCHOVER (Mains>UPS / UPS>Mains) | AUTOMATIC |
| UPS TRANSFER TIME | <15msec |
| TECHNOLOGY | |
| DESIGN | Micro Controller Based Design With IPS Technology |
| BATTERY CHARGING CURRENT | Constant Charging Approx. 10% of the Rated Battery Current in AH |
| UPS OVERLOAD / UPS SHORT CIRCUIT | 110% / 300% |
| BROWNS ON MAINS VOLTAGE | 100V +40V |
| EFFICIENCY (BATTERY MODE) | >84% |
| AUTO RESET FEATURE | YES |
| OPERATING TEMPRATURE | -20°~45° Degree Celsius |
| WEIGHT (KG) | 10 KG |
| DIMENSION (LxWxH) in CM | 34.4x39x20.7 CM |
